• Compliant with IMO and MSC standard.

• Small size, Light weight, Easy installation.

• All data with big letters can be displayed in one screen.

• Interface with PC to print out destination, mark and routes.

• No need to initially set-up the machine as it is of full automation.

• Easy night navigation with full light support in screen at every stage.

• Has temporary plotter function.

• WGS-84 and other way of geodetic survey can be selectable.

Specifications

• Receiver Frequency : L1 1575.42 MHZ (C/A code)

• Display Resolution : 128×64 dot LCD(3inch)

• Receiving Type : Digital 12 Channels multi tracking type

• Receiving Sensitivity : below -130dBm

• Resolution : 1/1000 Lat. and Longitude

• Accuracy :

- In case of GPS, Position : 10m 2D RMS (HDOP〈 2)( SA OFF)

- In case of DGPS, Position : 3m 2D RMS (HDOP〈 2)( SA OFF)

• Speed Accuracy : 0.1Knots RMS(HDOP<2, SA OFF)

• Destination Memory : WAYPOINT/MARK/MOB 1000 points in total

• Mark : position, course, average speed, destination, accessing speed, name of destination, route navigation, distance to destination, direction, time reguired, secession from route

• Display Mode : Temporary plotter mode, Steering mode, Highway mode, Navigation Data mode, User mode(Digital, Speedometer)

• Plotter mode : 0.02, 0.05, 0.1, 0.2, 0.5, 1, 2.5, 19, 20, 50, 160, 320nm

• Highway mode : 0.2, 0.4, 0.8, 1, 2, 4, 8 16nm

• Temperature : Main : -20℃~+55℃, Antenna : -40℃~+85℃

• Relative moisture : 0~95%

• Input/ Output of Data

- INPUT RS-232C, OPUPUT RS-232C & TTL

- SAMYUNG, NMEA 0183(Ver1.5, 2.0), FURUNO(CIF), JRC

• Power Supply : DC 10 ~ 36V / 0.08~0.3A(Max. below 4W)
